Ruck axial fan / EM 355 EC 01 / RV-130712
Plastic fan
949,62 €
Includes 19% MwSt.
plus shipping
Delivery Time: 3-4 weeks
Additional costs (e.g. for customs or taxes) may occur when shipping to non-EU countries.10 in stock
Description
Ruck Etamaster diagonal fan made of plastic
Additional information
| Weight | 8 kg |
|---|---|
| Matchcode | EM 355 EC 01 |
| Product group | Diagonal fan |
| Designation | Etamaster |
| Wing diameter [cm] | 35, 5 |
| Motor technology | EC 1~230V |
| Rated frequency fN [Hz] | 50 |
| Input power P1 [kW] | 0, 261 |
| Rated current IN [A] | 1, 82 |
| Rated speed nN [min-1] | 2170 |
| Min. permissible pumped liquid temperature [°C] | -30 |
| Max. permissible pumped liquid temperature [°C] | 35 |
| Sound pressure level LpA or LwA [dB(A)] | 50-52 |
| Protection class | IPX4 |
| Sash version | Plastic |
| Wall ring plate | Plastic housing |
| Conformity | ErP 2015 |
| Design | Pipe connection diameter DN355 |
| Volume flow at 0 Pa [m³/h] | 3320 |
| Max. pressure psf [Pa] | 278 |
| Volume flow at max. pressure [m³/h] | 1839 |
| Performance data | Overall efficiency 77, 5% |
