ZIEHL-ABEGG Axial fan / FC035-4DQ.2C.A7 / ZV-125090

Name: ZIEHL-ABEGG Axial fan / FC035-4DQ.2C.A7 / ZV-125090
SKU: ZV-125090
Availability: InStock

Standard

308,21 €

Includes 19% MwSt.

Delivery Time: approx. 5 working days

Additional costs (e.g. for customs or taxes) may occur when shipping to non-EU countries.

1 in stock

SKU: ZV-125090

Additional information

Weight	7 kg
Matchcode	FC035-4DQ.2C.A7
Product group	Axial fan
Wing diameter [cm]	35
Rated frequency fN [Hz]	50
Input power P1 [kW]	0, 170
Rated current IN [A]	0, 37
Rated speed nN [min-1]	1370
Max. permissible pumped liquid temperature [°C]	70
Sound pressure level LpA or LwA [dB(A)]	74
Protection class	IP54
Motor protection	Thermostat switch
Sash version	Aluminum, 1-layer lacquering, black
Rotor	Aluminum, 1-layer lacquering, black
Wall ring plate	Sheet metal
Conformity	ErP 2015
Design	Q
Volume flow at 0 Pa [m³/h]	3650
Max. pressure psf [Pa]	80
Volume flow at max. pressure [m³/h]	2400
